Hardened Steel Self Lubricating Bearing With Oilless Dry
Lubrication
Product Specification
| Product Name | Hardened Steel Bushings |
| Material Details | Steel base, Bronze powder, layer |
Max Load Capacity | Static load | 250N/mm² |
| Dynamic load | 140 N/mm² |
Max PV Value Limit | Dry friction | 3.6 N/mm² m/s |
| Oil lubrication | 50 N/mm² m/s |
Max Sliding Speed | Dry friction | 2.5m/s |
| Oil lubrication | 5.0 m/s |
Friction Coefficient | Dry friction | 0.08-0.20 |
| Oil lubrication | 0.02-0.08 |
| Termal Conductivity | 41 W/m k |
| Coefficient Thermal Expansion | 0.0001/K |
Product Description
Self lubricating Hardened Steel Bushings used high quality low-carbon steel plate as base, sintered porous
bronze as its interlayer and the Compound of and Lead as its
surface. It offers the property of good self-lubrication, low wear,
low frication, good sliding characteristics, low noise.
When using, do not need to oil or less oil, reduce oil cost, reduce
oil pollution to the environment.At the same time, it greatly
reduces the maintenance cost of bearing
It has been widely applied to various mechanical sliding postions,
such as texitile machinery, printing machinery, hydraulic pressure
transit vehicle, tobacco machinery, gymnastic instrument and
agricultural machinery etc.
Product Application
With the advantages of light weight, low noise and self-lubricating
features, Steel bushings are widely used in the automotive
industrial and the applications are still under fast developing.
Currently, there are over 50 bushings being used in each of the
passenger cars and more and more traditional needle bearing,
sintered bearings are been replacing by the self-lubricating
bushings.
In addition to the bushing, the self-lubricating materials are
applied to the other non-bearing parts such as the new resin coated
air conditioner swash plate and other structure parts had already
developed. Steel self-lubricating materials provide not only
functional parts to the automotive industry but also provide a
solution to this industry for environment protection with the
materials conform with RoHS and REACH regulations.
Product Advantage
1. Dry or only a trace amount of grease or ill will be required.
Maintenance free.
2. Low friction with long life.
3. Load spreads over a wider area due to the elastic nature of the
bearing materials, resulting in a higher loading capacity.
4. The small differences between static and dynamic coefficient of
friction enhance the accuracy of machines operating at low speeds.
5. Low vibration, low noise and reduced-pollution during operation.
6. and lead can form transfer films onto the mating surface to
improve performance and prevent bushing binding.
Competitive Advantage
1. We provide products with good quality at best price for clients
in quick delivery.
2. 100% custom pass guaranteed.
3. Always immediate and best after-sale service.
4. Flexible and negotiable payment terms.
5. Our clients distribute widely, like in UK, France, Germany, Norway, Poland, Finland, Spain, Russia,USA, Canada,
Brazil, Mexico, Australia, Japan, Thailand, Indonesia, Uruguay and
many other countries.
Packaging and Delivery
Inner Packing: 100 Pieces per Anti-rust plastic film, Vacuum
Plastic Bags.
Outer Packing: 1000-2000 Pieces per Hard Carton, Wooden Case,
Wooden Pallet.
Shipment Packing: 20 Carton per Wooden Case or Pallet
Shipping Term: By Express, By Air, By Land, By Sea.
Delivery Time: General 10-20 Work Days, (Depends on the Amount)
Delivery Term: FOB, CFR, CIF, EXW
